Toyota Core Electric Forklift

Performance, Efficiency, Reliability

The Toyota Core Electric Forklift is an ideal compact four-wheel electric lift truck solution for most indoor and warehouse applications. The Core Electric Forklift can move almost any load while operating in spaces as narrow as 11 feet. The AC motor offers new levels of performance, efficiency, and reliability, maximizing your productivity and return on investment.

Forklift Maintenance Plan Available: Extend the equipment’s lifespan, maintain its resale value, and make maintenance budgeting more predictable.

Request a Quote

Toyota Core Electric Brochure Toyota Core Electric Spec Sheet

Specs

Filter by: Load Capacity

Model Number	Load Capacity	Max Full Load Travel Speed	Max Full Load Lift Speed	Max Full Load Gradeability	Basic Right Angle Stack**
8FBC15U	3,000 lbs	36 V: 9.0 mph / 48 V: 10.9 mph	36 V: 61 fpm / 48 V: 85 fpm	36 V: 20% / 48 V: 21%	82.1"
8FBC18U	3,500 lbs	36 V: 8.7 mph / 48 V: 10.6 mph	36 V: 61 fpm / 48 V: 81 fpm	36 V: 18% / 48 V: 20%	82.1"
8FBCU20	4,000 lbs	36 V: 9.9 mph / 48 V: 11.5 mph	36 V: 67 fpm / 48 V: 89 fpm	36 V: 25% / 48 V: 23%	87.2"
8FBCU20-COMP	4,000 lbs	36 V: 9.9 mph / 48 V: 11.5 mph	36 V: 67 fpm / 48 V: 89 fpm	36 V: 25% / 48 V: 23%	85.2"
8FBCU25	5,000 lbs	36 V: 9.9 mph / 48 V: 11.5 mph	36 V: 59 fpm / 48 V: 79 fpm	36 V: 21% / 48 V: 19%	87.6"
8FBCU25-COMP	5,000 lbs	36 V: 9.9 mph / 48 V: 11.5 mph	36 V: 59 fpm / 48 V: 79 fpm	36 V: 21% / 48 V: 19%	85.6"
8FBCHU25	5,000 lbs	36 V: 9.9 mph / 48 V: 11.5 mph	36 V: 59 fpm / 48 V: 79 fpm	36 V: 21% / 48 V: 24%	93.1"
8FBCU28	5,500 lbs	36 V: 9.3 mph / 48 V: 11.5 mph	36 V: 55 fpm / 48 V: 73 fpm	36 V: 17% / 48 V: 20%	90.3"
8FBCU30	6,000 lbs	36 V: 9.0 mph / 48 V: 11.2 mph	36 V: 51 fpm / 48 V: 69 fpm	36 V: 17% / 48 V: 20%	94.9"
8FBCU32	6,500 lbs	36 V: 9.0 mph / 48 V: 11.2 mph	36 V: 47 fpm / 48 V: 65 fpm	36 V: 17% / 48 V: 19%	96.4"

Model Number	Load Capacity
8FBC15U	3,000 lbs
8FBC18U	3,500 lbs
8FBCU20	4,000 lbs
8FBCU20-COMP	4,000 lbs
8FBCU25	5,000 lbs
8FBCU25-COMP	5,000 lbs
8FBCHU25	5,000 lbs
8FBCU28	5,500 lbs
8FBCU30	6,000 lbs
8FBCU32	6,500 lbs

Model Number	Max Full Load Travel Speed
8FBC15U	36 V: 9.0 mph / 48 V: 10.9 mph
8FBC18U	36 V: 8.7 mph / 48 V: 10.6 mph
8FBCU20	36 V: 9.9 mph / 48 V: 11.5 mph
8FBCU20-COMP	36 V: 9.9 mph / 48 V: 11.5 mph
8FBCU25	36 V: 9.9 mph / 48 V: 11.5 mph
8FBCU25-COMP	36 V: 9.9 mph / 48 V: 11.5 mph
8FBCHU25	36 V: 9.9 mph / 48 V: 11.5 mph
8FBCU28	36 V: 9.3 mph / 48 V: 11.5 mph
8FBCU30	36 V: 9.0 mph / 48 V: 11.2 mph
8FBCU32	36 V: 9.0 mph / 48 V: 11.2 mph

Model Number	Max Full Load Lift Speed
8FBC15U	36 V: 61 fpm / 48 V: 85 fpm
8FBC18U	36 V: 61 fpm / 48 V: 81 fpm
8FBCU20	36 V: 67 fpm / 48 V: 89 fpm
8FBCU20-COMP	36 V: 67 fpm / 48 V: 89 fpm
8FBCU25	36 V: 59 fpm / 48 V: 79 fpm
8FBCU25-COMP	36 V: 59 fpm / 48 V: 79 fpm
8FBCHU25	36 V: 59 fpm / 48 V: 79 fpm
8FBCU28	36 V: 55 fpm / 48 V: 73 fpm
8FBCU30	36 V: 51 fpm / 48 V: 69 fpm
8FBCU32	36 V: 47 fpm / 48 V: 65 fpm

Model Number	Max Full Load Gradeability
8FBC15U	36 V: 20% / 48 V: 21%
8FBC18U	36 V: 18% / 48 V: 20%
8FBCU20	36 V: 25% / 48 V: 23%
8FBCU20-COMP	36 V: 25% / 48 V: 23%
8FBCU25	36 V: 21% / 48 V: 19%
8FBCU25-COMP	36 V: 21% / 48 V: 19%
8FBCHU25	36 V: 21% / 48 V: 24%
8FBCU28	36 V: 17% / 48 V: 20%
8FBCU30	36 V: 17% / 48 V: 20%
8FBCU32	36 V: 17% / 48 V: 19%

Model Number	Basic Right Angle Stack**
8FBC15U	82.1"
8FBC18U	82.1"
8FBCU20	87.2"
8FBCU20-COMP	85.2"
8FBCU25	87.6"
8FBCU25-COMP	85.6"
8FBCHU25	93.1"
8FBCU28	90.3"
8FBCU30	94.9"
8FBCU32	96.4"

*Based on 24″ load center
**Add load length and clearance. Product specifications may not reflect the most current product details. Authorized Toyota dealers retain the most current product specifications. All specifications should be verified by an authorized Toyota dealer representative prior to purchase.

Load Capacity

3,000 – 6,500 LBS

Full Load Travel Speed

9.7 – 10.2 MPH

Electrical System

36 / 48 V

Request a Quote

Overview

The Toyota Core Electric Forklift is an efficient, compact, four-wheel electric lift truck ideal for most indoor and warehouse applications, capable of handling loads up to 6,500 pounds. Key features include Toyota-designed AC motors for performance and efficiency, ergonomic controls for operator comfort, and safety systems like System of Active Stability (SAS) to prevent tip-overs. The forklift also offers various options, including narrow aisle models, and safety enhancements such as SEnS+ (Smart Environment Sensor Plus) and automatic slope assist.

Performance

AC drive system
UL Approved Type E
Three forms of energy regeneration
Digital LCD multifunction display
Adjustable front headlights
Punched plate entry/exit step

Ergonomics

Strategically configured instrument display
On-demand hydrostatic power steering
Dual operator assist grips
11.8″ diameter two-spoke steering wheel
Cowl-mounted hydraulic controls
Heavy-duty non-slip floor mat
Electric directional shift control

Safety Features

System of Active Stability (SAS)
Operator Presence Sensing System (OPSS)
Bolt-on overhead guard
Key lowering interlock
Foot activated parking break
Manual return to neutral

Ease of Service

AC drive motor
Easy access hydraulic motor
Easy access no-tools floorboard
Battery compartment hood assist
Planned maintenance indicator
Easy access controllers

					Options


							Planned Maintenance
								Reduce downtime, lower overall repair costs, and improve safety and compliance.

							Narrow Aisle Turret Mast
								Rotating turret head enables stacking without needing to turn the forklift

							T-Matics Vehicle Management System
								Real-time monitoring of forklift usage, operator performance, and maintenance needs

							Short Model
								More compact for constricted areas

							Cold Storage Package
								Enclosed cabin and heaters

							EZ Pedal
								Change the direction of travel with your foot

							Mini Lever Controls with Ergoshift
								Single, ergonomic control unit with a forward/reverse directional switch

							Cascade Integral Sideshifter
								Enhanced capacity and operator visibility

							Active Steering Synchronizer
								Ensures the steering wheel is always aligned with the rear steer wheels

							Battery Slide-Out
								Improves safety, increases productivity by allowing the battery to be extracted horizontally
