JLG Electric Compact Crawler Booms Aerial Lift
Boom Lifts that Climb Slopes
JLG’s Electric Compact Crawler Booms feature low weight and rubber tracks that allow you to go more places around the job site. They are environmentally friendly with standard AC power, gas, or an optional lithium-ion electrical system that doesn’t produce emissions. These boom lifts climb slopes with ease thanks to their tracked wheel carriage, and their narrow chassis allows for access through gates, yards, standard doorways, and public buildings.
Specs
| Model Number | Machine Width | Machine Lenght | Machine Height | Working Height | Outrigger Footprint Length | Outrigger Footprint Width | Platform Size |
|---|---|---|---|---|---|---|---|
| X430AJ | 2' 5" | 13' 2" | 6' 6" | 43' | 9' 2" | 9' 2" | 58 x 30" |
| X500AJ | 2' 7" | 14' 10" | 6' 7" | 56' | 10' 5" | 10' 6" | 58 x 30" |
| X600AJ | 2' 7" | 16' 5" | 6' 7" | 66' | 10' 7" | 10' 7" | 58 x 30" |
| X770AJ | 3' 3" | 20' 9" | 6' 7" | 84' | 14' | 13' 6" | 58 x 30" |
| X1000AJ | 3' 11" | 21' 3" | 6' 7" | 106' | 20' 8" | 16' 5" | 63 x 28" |
| Model Number | Machine Width |
|---|---|
| X430AJ | 2' 5" |
| X500AJ | 2' 7" |
| X600AJ | 2' 7" |
| X770AJ | 3' 3" |
| X1000AJ | 3' 11" |
| Model Number | Machine Lenght |
|---|---|
| X430AJ | 13' 2" |
| X500AJ | 14' 10" |
| X600AJ | 16' 5" |
| X770AJ | 20' 9" |
| X1000AJ | 21' 3" |
| Model Number | Machine Height |
|---|---|
| X430AJ | 6' 6" |
| X500AJ | 6' 7" |
| X600AJ | 6' 7" |
| X770AJ | 6' 7" |
| X1000AJ | 6' 7" |
| Model Number | Working Height |
|---|---|
| X430AJ | 43' |
| X500AJ | 56' |
| X600AJ | 66' |
| X770AJ | 84' |
| X1000AJ | 106' |
| Model Number | Outrigger Footprint Length |
|---|---|
| X430AJ | 9' 2" |
| X500AJ | 10' 5" |
| X600AJ | 10' 7" |
| X770AJ | 14' |
| X1000AJ | 20' 8" |
| Model Number | Outrigger Footprint Width |
|---|---|
| X430AJ | 9' 2" |
| X500AJ | 10' 6" |
| X600AJ | 10' 7" |
| X770AJ | 13' 6" |
| X1000AJ | 16' 5" |
| Model Number | Platform Size |
|---|---|
| X430AJ | 58 x 30" |
| X500AJ | 58 x 30" |
| X600AJ | 58 x 30" |
| X770AJ | 58 x 30" |
| X1000AJ | 63 x 28" |
Product specifications may not reflect the most current product details. Authorized JLG dealers retain the most current product specifications. All specifications should be verified by an authorized JLG dealer prior to purchase.
Overview
JLG’s Electric Compact Crawler Boom Lifts, also known as spider lifts, are narrow, lightweight, tracked machines designed for indoor and outdoor access to difficult-to-reach areas. They are powered by silent, clean lithium-ion battery systems for eco-friendly operation and feature rubber tracks for traction on slopes and sensitive surfaces.
Performance
- Outstanding horizontal reach
- Lithium-ion power system
- Easily lifted by a forklift or crane thanks to forklift pockets and lifting eyes
- Drive speed control
- Regenerative valve on telescopic cylinder
- Fits through a standard doorway
- Auto levels on uneven surfaces
Ergonomics
- Narrow chassis
- Reduced vibrations
- Emission-free operations
Safety Features
- Load-sensing system
- removable controller
- Emergency lowering
- Automatic outrigger leveling
- High gradeability
- Automatic leveling
Ease of Service
- Integrated power system
- Easy to transport
- Low weight
- Onboard diagnostics
